1. Product Overview
Slim Post Composite 30% Diameter GIS are core insulating support parts built exclusively for new small integrated GIS gas-insulated switchgears. This product group includes integrated built-in GIS support insulators, mini integrated GIS post insulators and other matching styles under the Slim Post Composite 30% Diameter GIS series.
Old-style insulators carry many structural drawbacks. Slim Post Composite 30% Diameter GIS adopt upgraded raw materials and use electric field simulation to polish the whole structure design. The series keeps strong insulation performance, solid load-bearing ability and stable anti-weather performance. Each unit is 30% slimmer than traditional insulators, so users can install Slim Post Composite 30% Diameter GIS directly inside sealed GIS tank bodies.
The main job of Slim Post Composite 30% Diameter GIS is to fix high-voltage conductive bars inside GIS tanks. It separates different circuit loops, blocks electric current flow and stops electric leakage to the ground. Traditional insulators usually take too much inner space, waste raw materials and create complex assembly work. Slim Post Composite 30% Diameter GIS solve all these common pain points at once.
People can install Slim Post Composite 30% Diameter GIS on brand-new GIS devices for power plants, nuclear power stations, new energy power stations and special industrial power supply equipment. It also fits renovation work for outdated power gear. Designers rely on Slim Post Composite 30% Diameter GIS to make high-voltage switches smaller, lighter and more compactly integrated.
2. Core Design
2.1 Smaller Diameter Optimized Design
Engineers run computer electric field simulation to adjust the inner electric field of Slim Post Composite 30% Diameter GIS. They remove risky zones with over-concentrated local electric charge. The team cuts redundant insulating layers from old insulator designs. Every Slim Post Composite 30% Diameter GIS uses tough epoxy glass fiber as the inner core rod, wrapped with high-performance silicone rubber outer protection. The whole diameter shrinks by 30% while the product fully passes all insulation safety tests.
Designers also rearrange the outer umbrella-shaped protrusions of Slim Post Composite 30% Diameter GIS into narrow compact shapes to greatly cut self-weight. This layout stops messy air flow and dust buildup inside sealed GIS tanks, making Slim Post Composite 30% Diameter GIS perfectly fit the fully closed running environment of GIS devices.
2.2 Integrated Built-in Design for GIS
We tailor Slim Post Composite 30% Diameter GIS for the special working conditions of sealed metal GIS cavities. Its outer shape and mounting interfaces fully match the inner structure of GIS cylinders. Users do not need extra connecting brackets, so Slim Post Composite 30% Diameter GIS support zero-waste assembly inside equipment cavities.
The two ends of each Slim Post Composite 30% Diameter GIS use precise one-piece crimp technology. This design removes tiny air gaps between core rods and metal fittings, and lowers partial discharge risks from the root. Slim Post Composite 30% Diameter GIS work smoothly with sealed SF₆ insulating gas. They resist electric arcs and gas decomposition products, and hold low gas permeability. Each Slim Post Composite 30% Diameter GIS can run stably for years under sealed pressure inside GIS equipment.
2.3 Modular Miniature Adaptable Design
All Slim Post Composite 30% Diameter GIS follow unified standard modular sizes. They fit every functional cabin of GIS gear, such as circuit breaker cabins, conductive bar cabins and transformer cabins.
Workers pre-assemble each Slim Post Composite 30% Diameter GIS inside factories. Field workers only use simple screws to lock the product in place. No on-site cutting or splicing is needed, which speeds up full GIS assembly work sharply.
Slim Post Composite 30% Diameter GIS match mainstream GIS and HGIS switchgears of common voltage grades sold worldwide. Our team also adjusts the size of Slim Post Composite 30% Diameter GIS to match special equipment structures from different manufacturers.
3. Key Product Advantages
3.1 Small Size Saves Equipment Space
Slim Post Composite 30% Diameter GIS cut insulator diameter by 30%, so supporting GIS conductive cylinders can become thinner accordingly. A full set of switch gear takes 20% to 30% less overall space. Slim Post Composite 30% Diameter GIS work well for indoor city substations, underground pipe gallery power stations, offshore wind tower equipment and narrow nuclear power plant machine rooms. The product largely cuts factory construction costs for power projects.
3.2 Stable Performance for Safe Operation
Slim Post Composite 30% Diameter GIS carry smaller outer sizes but keep all core performance standards. After electric field optimization, its insulation strength, power frequency withstand voltage and lightning shock resistance all beat official national limits.
We build Slim Post Composite 30% Diameter GIS with composite materials, unlike old ceramic insulators that crack, split or explode easily. Slim Post Composite 30% Diameter GIS stand strong hits, earthquakes and thick dust pollution. They bear huge electric impact from short circuits, earthquake shaking, extreme heat and freezing cold. Long-time use rarely causes partial discharge or insulation aging on Slim Post Composite 30% Diameter GIS, so later maintenance risks stay very low.
3.3 Less Raw Materials, Eco-friendly and Cost-saving
The slim body of Slim Post Composite 30% Diameter GIS reduces raw material consumption per single unit and lowers total production costs. It also cuts steel use for GIS cylinders and filling SF₆ insulating gas. Less greenhouse gas output meets low-carbon and carbon neutral development goals.
Full sets of equipment using Slim Post Composite 30% Diameter GIS weigh much less, so transport, lifting and installation costs drop. Every stage of the project saves money and finishes construction faster.
3.4 Fast Assembly, Fits New and Old Projects
The integrated structure of Slim Post Composite 30% Diameter GIS simplifies assembly steps and lifts construction efficiency by over 40%. It shortens both equipment production cycles and whole project building time.
Standard mounting ports on Slim Post Composite 30% Diameter GIS match both new and old power equipment. Factories install Slim Post Composite 30% Diameter GIS on new GIS switchgears during mass production. Construction crews also directly replace old traditional insulators with Slim Post Composite 30% Diameter GIS in outdated power stations, with no changes needed to main GIS structures. The product supports easy renovation and has extremely wide compatibility.
4. Typical Application Scenarios
| Serial Number | Application Field | Detailed Usage Scenarios | Core Matching Advantages of Slim Post Composite 30% Diameter GIS |
|---|---|---|---|
| 1 | Urban Power Transmission Projects | Small indoor urban GIS substations, underground pipe gallery substations, renovation of old substation equipment | Slim Post Composite 30% Diameter GIS fit crowded city zones that require compact power equipment layout |
| 2 | Nuclear Power Systems | GIS switches for main nuclear power units and supporting facilities | Slim Post Composite 30% Diameter GIS pass strict nuclear standards for strong earthquake resistance, high reliability and multi-year stable operation |
| 3 | New Energy Power Generation | Small GIS devices for onshore wind farms & centralized photovoltaic booster stations; built-in GIS switches inside offshore wind towers | Slim Post Composite 30% Diameter GIS match lightweight design and narrow installation space of new energy equipment |
| 4 | Special Industrial Power Supply | Complete GIS equipment for metallurgy, chemical and other industries with high power stability requirements; used in high-altitude, coastal salt-fog and heavy industrial dust environments | Slim Post Composite 30% Diameter GIS resist harsh working conditions and keep steady power supply |
| 5 | Domestic & Overseas Infrastructure | New domestic and foreign high-voltage transmission projects, GIS upgrading of old power stations, supporting switch sets exported to overseas power grids | Slim Post Composite 30% Diameter GIS work for new construction and equipment renovation projects all over the world |
5. Model Selection Guide
5.1 Select by Voltage Level
Slim Post Composite 30% Diameter GIS cover mainstream high voltage grades: 35 kV, 110 kV, 220 kV and 252 kV. Pick the correct model of Slim Post Composite 30% Diameter GIS based on grid standard voltage, insulation creepage distance and voltage resistance indexes.
5.2 Select by Working Environment
- Standard city working areas: standard type Slim Post Composite 30% Diameter GIS
- Coastal salt fog or heavy industrial pollution zones: anti-pollution reinforced Slim Post Composite 30% Diameter GIS
- High-intensity earthquake zones and nuclear power sites: shock-resistant high mechanical strength Slim Post Composite 30% Diameter GIS
- Frigid low-temperature regions: special low-temperature silicone rubber Slim Post Composite 30% Diameter GIS
5.3 Select by Equipment Structure
We provide two structural types of Slim Post Composite 30% Diameter GIS: single independent unit and three-phase integrated cabinet. Choose the model according to GIS cylinder inner diameter, mounting flange hole size and circuit spacing inside equipment cabins. We accept non-standard custom orders and adjust the height, thickness and interface size of Slim Post Composite 30% Diameter GIS following customers’ equipment drawings.
5.4 Select by Project Type
- New complete GIS equipment: Match corresponding Slim Post Composite 30% Diameter GIS models during equipment design stages
- Old equipment renovation: Choose universal replacement Slim Post Composite 30% Diameter GIS for direct on-site swap, no changes to main equipment required
6. Compliance Standards
Every stage of Slim Post Composite 30% Diameter GIS — from design drawing, factory production, factory inspection to final acceptance — follows strict Chinese national standards, industrial codes and global IEC standards. Key standards are listed below:
6.1 Domestic Standards
- GB/T 25096-2010: Composite Station Post Insulators for AC Voltages above 1000 V – Definitions, Test Methods and Acceptance Rules
- GB/T 26218.3-2011: Selection and Dimensioning of High-Voltage Insulators for Polluted Conditions
- DL/T 617: Technical Specifications for Gas Insulated Metal-enclosed Switchgear
6.2 International Standards
- IEC 62231:2006: General Specification for Composite Station Post Insulators
- IEC 62772-2023: Test and Acceptance Rules for High-Voltage Composite Post Insulators
6.3 Special Standards
Slim Post Composite 30% Diameter GIS satisfy special safety and seismic acceptance rules for nuclear electrical equipment. They run steadily in high-risk, harsh working environments.
7. Product Summary
Slim Post Composite 30% Diameter GIS, with a 30% reduced diameter and full compatibility with integrated GIS switches, are core insulating accessories for new small integrated high-voltage GIS equipment.
